Leica microscope: 10 × magnification / 100 mm work distance
Product description
This modular laser welding system was specially developed for deposition welding of large tools up to 25 tons. Thanks to their long reach of up to 1,830 mm radius and the long travel distances of the individual axes, the systems in this series offer a high level of flexibility in the repair of components – regardless of size or geometry.
Highest precision and mobility
The stable, torsion-resistant construction and smooth-running axles enable high precision during machining. The movable construction on swivel castors also ensures maximum mobility. In transport position, the rotating and swivelling arm can be stably moved and flexibly positioned. The removable display also facilitates the operation of the system and reliable control of the laser parameters.
Advantages of the basic version at a glance
Flexible joystick
With the multifunctional joystick, our laser welding systems can be controlled with extreme precision, speed and convenience. Many application-oriented functions such as automatic pulse control, the activation of a fourth axis (turning device) or switching between analogue and digital operating modes are already implemented in the joystick as a standard.
Advantages at a glance:
- Analogue and digital operation possible
- Jog-off function
- Vmax function for fast positioning
- Coordinate invert function
- Control the fourth axis: Control of a motorized turning device is already integrated
- Freely programmable keys for own applications
- Automatic pulse
Removable display
The removable display with magnetic holder simplifies the operation of all our systems as well as the control of all process data. With 50 memory locations, you can save various welding parameters and call them up at any time.
Advantages at a glance:
- Storage locations for welding parameters
- Removable, magnetic display with 1.5 m cable
- High reliability due to redundancy of the controls
- Introduction for the path control software Sigomatic
- Easy readout of operating data, such as pulse rate or operating hours
