Removable Magnetic Display for Laser Welding | Full Sigomatic Control

Name: Removable Magnetic Display for Laser Welding | Full Sigomatic Control | Sigma Laser
Brand: Sigma Laser

Full Control, Right Where You Need It
Simplify and streamline your welding workflow with Sigma’s Removable Magnetic Display — the intuitive control center for all Sigma laser welding systems.

Designed for flexibility and efficiency, this display mounts magnetically and connects via a 1.5-meter cable, giving you freedom of placement while keeping your setup tidy and ergonomic. Its built-in memory supports up to 50 stored welding parameter sets, making repeat jobs and quick setup changes effortless.

With seamless Sigomatic software integration, navigating through path control settings becomes faster and more intuitive than ever. Whether you’re adjusting pulse rates or reviewing machine operating hours, all data is clearly readable and instantly accessible.

This detachable display also introduces a redundant control system, enhancing reliability and reducing the risk of operation failure — especially crucial in continuous or high-precision production environments.

Key Features at a Glance:

Up to 50 memory slots for welding parameters
Removable magnetic mount with 1.5 m flexible cable
Redundant control electronics for maximum reliability
Full Sigomatic software support for smart path programming
Live readout of pulse rate, operating hours, and more

Quick Access to Sections:

The Removable Laser Welding Display System is a highly efficient control and monitoring interface designed to give operators full access to welding parameters and system performance data. Built with precision and reliability in mind, this detachable unit enhances usability across all Sigma Laser welding systems.

Specifications Table

Feature	Description
Display Type	Digital LCD with high-contrast readability
Mounting System	Magnetic holder (detachable)
Connection Cable Length	1.5 meters
Memory Capacity	50 welding parameter presets
Redundancy	Dual control redundancy for increased reliability
Data Readout Functions	Pulse rate, total operating hours, and live system feedback
Software Integration	Full integration with Sigomatic path control software
User Interface	Menu-driven UI with parameter navigation
Power Source	Powered through main welding system (no separate power needed)
Weight	~300g
Operating Temperature Range	0°C to 50°C

Detailed Features

Removable & Magnetic Design

Thanks to its magnetic holder and detachable format, the display can be easily removed and repositioned during setup or operation without tools. The 1.5-meter cable gives users flexibility in placement.

50 Preset Memory Locations

Operators can save up to 50 customized welding parameter sets, ensuring consistent quality and fast setup for repeat jobs.

Real-Time Process Monitoring

Access essential data such as pulse frequency, operating hours, and system performance metrics at a glance.

Redundant Control Safety

The built-in control redundancy ensures uninterrupted operation, reducing risks during critical welding processes.

Sigomatic Software Integration

Seamlessly operates with Sigomatic, Sigma Laser’s advanced path control software, enabling intuitive navigation and parameter control directly from the display.

Intuitive Menu Navigation

An easy-to-use, multilingual interface guides the user through system settings, making training time minimal and operation efficient.

The Removable Display System is designed with flexibility and modularity in mind, ensuring seamless integration across a wide range of Sigma Laser’s industrial welding systems. Whether you’re working with automated setups or compact manual stations, this display unit enhances control and visibility without requiring additional configuration.

Compatible With:

Product Line	Model Series	Notes
Sidanus	Light, Ultra, Pro	Full software and hardware compatibility
Siega	Light, Edge	Direct integration with no firmware update required
Alphaweld	Standard, Smart	Compatible via Sigomatic interface; auto-parameter recognition
SigmaCore	Industrial Modules v3+	Supported with magnetic mounting; full data feedback enabled

Software Compatibility

Sigomatic Control Software
Native integration for real-time parameter adjustment, profile management, and diagnostics.
Firmware Versions
Compatible with firmware v2.3 and above (Display unit auto-detects system version on boot).

Connectivity Requirements

Cable Connector: 5-pin data + power combo
Mounting Interface: Magnetic surface (metal-enclosed systems)
No Additional Drivers Required – Plug-and-play functionality

Use Case Flexibility

Whether your welding station is fixed, mobile, or robotic, the Removable Display System adapts to your environment with:

Detachable magnetic placement
1.5m cable range

No interference with system shielding or safety protocols

The Removable Display System enhances usability and operational flexibility across diverse industrial environments. It empowers operators with clearer visibility, faster access to welding parameters, and more intuitive control – especially in demanding production settings where adaptability and precision are essential.

laser welding in medical devices and instruments

Medical Device Manufacturing

In the assembly of stainless steel and titanium surgical tools, the detachable display supports cleanroom protocols by reducing machine contact and simplifying inspection.

Tool and Mold Making

In workshops where machines are tightly spaced, the detachable display can be moved closer to the welding site for quicker setup verification and visual feedback.

laser welding in aerospace manufacturing

Aerospace & Defense

Enables safer and more ergonomic control of high-precision welds in compact fuselage sections or turbine components. Wireless functionality minimizes wiring clutter in sensitive zones.

Electronics & Battery Assembly

Improves parameter visibility during micro-welding of contacts, busbars, and PCB terminals. Allows operators to quickly adapt weld profiles without returning to the main console.

Automotive Manufacturing

Used in body assembly lines for precision laser welding of components like door frames, battery packs, and sensor housings. The removable display allows technicians to monitor real-time weld data on the go.

Custom Fabrication & Prototyping

For low-volume, high-mix production, the modular display simplifies job switching and ensures better control over non-repetitive weld cycles.

Key Advantages Across Applications

Advantage	Description
Mobility & Ergonomics	Operators can position the screen wherever visibility is optimal.
Improved Workflow Efficiency	Reduces back-and-forth movement, especially in multi-machine environments.
Operator Safety	Allows distance from hot zones or enclosure doors during setup.
Cross-Model Use	Can be used with multiple Sigma systems on the floor.
Adaptability in Tight Spaces	Ideal for compact workstations and mobile welding carts.

The Removable Display System is designed with adaptability in mind — ensuring seamless integration into diverse industrial environments and operator preferences. Sigma Laser offers various customization options to tailor the display system to your exact production needs and ergonomic requirements.

Available Customization Features

Feature	Description
Mounting Configuration	Choose between magnetic base, swivel arm, or rolling stand to optimize positioning and mobility.
Screen Size Options	Available in 7″, 10″, or 12″ touch screens for different visibility and space constraints.
UI Theme Customization	Adjust UI layout, color schemes, and font sizes to suit operator preferences and reduce eye strain.
Wireless Protocol Selection	Supports Wi-Fi 5 / Wi-Fi 6, with optional Bluetooth fallback for environments with unstable wireless coverage.
Button Layout Customization	Configure hardware shortcut buttons on the display frame (e.g., emergency stop, preset selection, zoom).
Logo & Branding	OEM branding available for machine integrators and distributors.
Language Support	Multi-language interface with the ability to load custom language packs.
Protective Casing Options	Choose between anti-static, dustproof, or IP65-rated waterproof enclosures.
Data Display Presets	Customize what welding parameters (power, pulse width, frequency, etc.) are shown by default on-screen.

Integration Flexibility

Compatible with all Sigma Laser Welding Systems (Siega Light, Sidanus, Dione, etc.)
Plug-and-play setup via USB-C or proprietary wireless dongle (included).
Multiple displays can be paired with a single welding unit (admin control enabled).
Optional docking cradle with charging and LAN passthrough available.

Custom Use Case?

If your workflow involves robotic arms, conveyor-driven parts, or cleanroom applications — our engineers can design a fully bespoke display system tailored to your unique setup.

Let us know your requirements — from hardware tweaks to UI modifications — and we’ll build a solution that fits your floor.

Answers to common questions about the Detachable Control & Display Interface for Laser Welding Systems:

Is this display system truly wireless?

Yes. The display connects via secure Wi-Fi (5/6) and can operate wirelessly within a 10–20 meter range, depending on your facility's structure. A wired fallback (USB-C) is also available if needed.

How long does the battery last?

The system uses an industrial-grade lithium battery that provides up to 8 hours of continuous use on a single charge. Standby time exceeds 24 hours. A charging cradle is included for convenience.

Can I install this on my existing Sigma laser welding system?

Yes. The display is fully compatible with all current Sigma Laser welding machines, including Siega Light, Sidanus, and Dione series. Older machines may require a firmware update.

How is the screen mounted?

You can choose between:

Magnetic base (for flat metal surfaces),
Swivel arm (for flexible positioning),
Rolling stand (for mobile use across stations).
Mounting options can be customized based on your workspace.

What wireless protocols are supported?

Wi-Fi 5 (802.11ac)
Wi-Fi 6 (802.11ax)
Optional fallback to Bluetooth 5.0 in environments with limited Wi-Fi.

What comes in the box?

1x Removable Display (preconfigured)
1x Mounting base (custom option)
1x Charging cradle
1x Wireless dongle (for pairing with main unit)
Quick Start Guide + Accessory pack

Can multiple displays be connected to one machine?

Yes, up to 2 displays can be connected simultaneously to a single welding unit, with admin control enabled on one of them.

Is the display waterproof or dustproof?

You can choose between standard or IP65-rated casing that is dustproof, splash-proof, and suited for demanding industrial environments.

Does it support different languages?

Yes, the system supports multi-language interfaces. Custom language packs can also be uploaded if your factory requires a specific dialect or terminology.

Best Practices for Setup, Automation, and Precision Control

Whether you’re new to Sigma Laser’s modules or looking to push your system to its full potential, these guides cover everything from installation to advanced automation workflows.

At Sigma Laser, our commitment to excellence doesn’t end at delivery. The Display comes with a full suite of after-sales services designed to ensure optimal performance, operator confidence, and long-term value from your investment. Whether you’re a small workshop or a multinational manufacturer, our support ecosystem keeps your production running smoothly.

Performance Optimization Consulting

For customers with high-throughput needs or complex applications, we offer:

Process auditing
Automation optimization
Custom software macros
Fixture design and integration consulting

Installation & Commissioning

Our team provides on-site setup, system calibration, and full integration into your existing workspace or automation line. We ensure everything is optimized from day one — including safety checks, software configuration, and trial welds.

Spare Parts & Consumables

We maintain a well-stocked inventory of Replacement lamps, Optical components, Cooling units and Wear parts. Fast shipping worldwide ensures minimal downtime.

Remote Diagnostics & Global Support

From preventive maintenance to rapid troubleshooting, our global service team keeps your laser welding equipment running with minimal downtime through on‑site visits and secure remote diagnostics.

Operator Training & System Onboarding

Hands‑on training programs give your staff the skills to operate, maintain, and optimize Sigma laser welding systems safely and productively right from day one.

Extended Warranty & Lamp Breakage Protection

Enjoy long‑term peace of mind with comprehensive warranty coverage—including exclusive lamp break protection—for all light‑pumped laser welding systems.

Proper maintenance ensures long-term accuracy, responsiveness, and safety of your laser welding Display. Follow the checklist below to keep your device in peak condition.

Daily Maintenance

Clean the display surface using a soft, lint-free cloth to remove dust and fingerprints.
Check the magnetic holder to ensure secure attachment and prevent accidental drops.
Inspect cable connections for any visible damage or looseness.
Verify wireless signal strength to ensure uninterrupted control.

Weekly Maintenance

Perform a system reboot to refresh software and clear temporary glitches.
Inspect the display housing for cracks or wear that may affect durability.
Check battery status if the display includes an internal battery or wireless power components.

Monthly Maintenance

Update firmware and software to the latest version to benefit from improvements and bug fixes.
Test all memory locations to ensure saved welding parameters are intact and accessible.
Review and clean connectors thoroughly to prevent corrosion or poor contact.

Long-Term Maintenance

Schedule calibration checks to maintain accurate readings and control.
Replace worn or damaged cables promptly to avoid signal interruption.
Evaluate magnetic holder strength and replace if magnetic force diminishes.
Perform comprehensive system diagnostics in coordination with Sigma Laser technical support.

Pro Tips for Professionals

Avoid using harsh chemicals or abrasive materials when cleaning the display.
Keep the display away from extreme temperatures and moisture.
Store the detachable display securely when not in use to prevent damage.
Regularly backup welding parameters externally for recovery after resets.

Maintenance Summary

Proper maintenance of your wireless welding display system ensures optimal performance, extends device lifespan, and prevents operational interruptions. Following this structured maintenance schedule helps maintain reliability and accuracy in your welding workflows.

A Complete Safety Framework for Industrial Laser Welding with Motion Components Ensuring operator safety and system integrity is crucial when working with advanced motion components like the Swivelling Y Axis. This tilting mechanism introduces dynamic movement into the laser welding system, which, while improving flexibility and reach, also requires strict adherence to safety protocols. From mechanical precautions to proper handling of laser exposure during angled operations, these guidelines help reduce risks and maintain compliance with industrial safety standards. Whether you’re performing routine maintenance, adjusting tilt angles, or integrating the axis into your system, following the correct safety practices ensures smooth, injury-free operation and prolonged equipment life.

Laser Safety Classification

The Z Axis is used within Class 1 laser systems (fully enclosed), or optionally with Class 4 open setups under operator control.
Always verify the enclosure is properly sealed when operating in Class 1 mode.
Operators must never enter the machine’s movement range while the axis is powered on.

Personal Protective Equipment (PPE)

Laser safety goggles (wavelength-specific)
Anti-static gloves for handling wiring or electronics
Steel-toe safety shoes when working near moving modules
Tight-fitting clothing to avoid snagging in motion systems

Task	Recommended PPE
Routine operation	No PPE required under closed housing
Maintenance (open casing)	Laser safety goggles (1064 nm rated)
Welding setup adjustments	Safety gloves, protective sleeves
Handling heavy components	Safety shoes, cut-resistant gloves
Optical cleaning or inspection	Anti-static gloves and lens-safe cloths

Workspace Safety Requirements

Maintain a clear zone of at least 1 meter around the Z-axis system
Ensure firm, vibration-free mounting of the entire assembly
Install indicator lights showing active laser or axis movement status
Enclosures must include interlocked access doors

Electrical & Cooling System Safety

Only trained personnel should connect power supplies
Ensure ambient temperature and humidity remain within safe operating limits
Passive or active cooling elements (if any) must be kept dust-free
Never bypass safety fuses, relays, or grounding components

Software & Control Warnings

Use only official Sigomatic software for motion control
Always home the axis before running a new program
Do not interrupt or power down while axis is in motion
Update software only under guidance of technical support

Emergency Procedures

Emergency Stop Button must be within operator’s reach at all times
Have a CO₂ fire extinguisher nearby for electronics and laser equipment
In case of collision or jamming, immediately shut off main power and inspect axis alignment

Training & Access Control

Only certified operators should access system controls
Password-protect control software on shared workstations
Keep updated safety manuals and SOPs accessible to all personnel

Safety Summary

Safety in vertical motion laser systems is not optional — it’s a requirement for accuracy, uptime, and team well-being. Sigma Laser recommends following ISO 11553 and local machine safety standards.

Sigma Laser Wireless Display System vs. Conventional Wired Controllers?

In modern laser welding environments, precision control and user convenience are critical. Sigma Laser’s Wireless Joystick and Detachable Display system sets a new standard by combining flexibility, advanced functionality, and ease of use—without the constraints of cables.

Here’s how it compares to traditional wired joysticks and basic manual controls:

Feature / Device	Sigma Wireless Joystick & Display	Wired Joystick Controllers	Manual Control Panels
Connection Type	✅ Wireless (Bluetooth or proprietary RF)	❌ Wired, limited mobility	❌ Manual, no electronic control
Mobility & Flexibility	✅ Full freedom of movement up to 10 m+	⚠️ Limited by cable length and routing	❌ Fixed at control panel
Control Functions	✅ Multifunctional: pulse control, 4th axis, programmable keys	⚠️ Limited multifunctionality	❌ Basic or no programmable features
Ease of Installation	✅ Plug-and-play, no cable management issues	⚠️ Requires cable routing and mounting	✅ Simple but limited in control
Display Integration	✅ Detachable magnetic display with data readout	⚠️ Typically fixed or no display	❌ No digital display
Compatibility with Sigma Systems	✅ Fully integrated	✅ Generally compatible	⚠️ Limited integration
Durability & Reliability	✅ High, with wireless encryption and redundancy	⚠️ Cable wear and potential connection faults	❌ Mechanical wear
User Convenience	✅ Ergonomic, wireless, and modular	⚠️ Restricted movement	❌ No ergonomic design
Best Use Case	Automated, flexible laser welding setups	Semi-automated, fixed stations	Basic manual welding tasks

Whether you need greater operator mobility, advanced programmable controls, or a clean setup free from cable clutter, the Sigma Wireless Joystick and Display system delivers superior performance and usability, making it the smart choice for modern laser welding operations.

Why choose the Sigma Laser Wireless Joystick and Display System?

Seamless Wireless Control for Maximum Flexibility

In laser welding, operator freedom and precision are essential. The Sigma Wireless Joystick and Detachable Display system offers unmatched mobility without the hassle of cables, enabling welders to position themselves optimally for every job. This freedom significantly enhances control accuracy and comfort, translating directly into higher-quality welds.

Multifunctional and User-Centric Design

Equipped with advanced functions such as automatic pulse control, integrated fourth-axis management, and programmable keys, the joystick streamlines complex welding operations. The detachable magnetic display provides instant access to crucial process data and parameter memory, making system monitoring and adjustments quick and intuitive.

Plug-and-Play Integration with Sigma Systems

Designed specifically for Sigma Laser’s manual welding machines, the wireless joystick and display integrate flawlessly with existing hardware and software ecosystems—no additional setup or configuration is needed. This seamless compatibility reduces downtime and accelerates deployment.

Key Benefits at a Glance:

Wireless Freedom: No cables, no restrictions—operate comfortably anywhere within range.
Comprehensive Control: Manage pulse settings, rotation axis, and more directly from the joystick.
Ergonomic and Modular: Detachable display with magnetic holder and user-friendly interface.
Reliable and Secure: Wireless communication with encryption ensures stable and safe operation.
Enhanced Productivity: Faster positioning, smoother workflow, and reduced operator fatigue.
Wide Industry Applicability: Ideal for automotive, aerospace, tool manufacturing, and precision engineering.

Upgrade Your Laser Welding Experience

Unlike conventional wired joysticks or basic manual panels, the Sigma Wireless Joystick and Display system was engineered for ease of use, adaptability, and professional-grade performance. Investing in this upgrade means smoother workflows, higher precision, and the freedom to work smarter—without compromise.

Contacts

Location

Phone

Email

Follow us

Folge uns

Siga-nos

Síganos

Removable Magnetic Display for Laser Welding Systems

Engineered for precision tasksTechnical Specifications of Removable Magnetic Display for Laser Welding Systems
